Tips & tricks 9 :Making Pine trees

Post  Ruben Lopez on Sun Nov 23, 2008 9:33 pm

Hi everyone, let me show you how I make a pine tree.

For the trunk I use a ¼ inch wood dowel. The length is up to you but keep in mind that you need to leave about ½ inch extra to insert it on the base. The one I’m going to make here will be about 10 ½ inches long. Then I use a pencil sharpener to make the point at the top. Using a rotary tool with a coarse sanding drum attached I give the dowel some texture by passing it lengthwise on the surface. (You are looking for irregularity here so make random passes.) You can also use 100 grit sandpaper but the rotary tool is faster.

Next, measure the point of the lower branches. (I usually put mine at about the same height as the figure’s head but that really depends of the type of tree you are making.)
Using that as a starting point mark every ½ inch till you reach the top. You should end up with something like this:


Then start drilling small holes around the trunk at every mark. I drill 6 holes in the lower part of the trunk, 5 around the middle and 4 closer to the top. Now paint the trunk. Later it will be harder to paint it due to the branches.


For the branches I use “Caspia” branches. I bought it at Michaels many years ago but you should be able to find it at florist shops. If you can’t find it, anything with the same look will work. The branch will determine the size of the holes in the trunk.


Now clamp the trunk on something and start inserting branches in the trunk until you get the correct shape for the pine you are making. This is the most time consuming part of the project. Pine trees tend to be conical, so I start with the lower branches, as they will be the longest ones. Then you have to trim the other ones until you reach the top. Trim the Caspia branches from the inside and dry fit them to the dowel to see the shape; if you feel it’s the correct shape put a drop of white glue to the branch and insert it.


When you reach the top you should have something like this:


Now take a can of your favorite spray adhesive and give a coat to the branches, flock them with static grass and let it dry.


And there you have it; your very own pine tree.
Thanks for your interest

Ruben

Ruben Lopez
seasoned veteran
seasoned veteran

Posts : 454
Join date : 2008-11-22
Age : 50
Location Location : Puerto Rico

Back to top Go down

Not bad, But

Post  Panzer on Wed Nov 26, 2008 10:05 pm

Ruben
The tree would look much better with a bunch more branches, good work.
Panzer

Panzer
General
General

Posts : 980
Join date : 2008-11-17
Age : 55
Location Location : O'Fallon MO, U.S. of A

http://www.network54.com/Forum/526495/

Back to top Go down

Re: Tips & tricks 9 :Making Pine trees

Post  Ruben Lopez on Thu Nov 27, 2008 4:19 pm

Yes Panzer, but this is a small (juvenile) pine tree that I was making. Considering that pine trees can grow between 15 and 45 meters tall a full grown tree at 1/35 would be between 17 and 50 inches tall so I think the distribution is ok for a tree this size (about 10 inches). Here it is in the base...


But rest assured I'll take your advise into account for the next one.
Thanks for the input.

Ruben

Ruben Lopez
seasoned veteran
seasoned veteran

Posts : 454
Join date : 2008-11-22
Age : 50
Location Location : Puerto Rico

Back to top Go down

There you go!

Post  Panzer on Thu Nov 27, 2008 7:39 pm

I am waiting to see the next one.
Panzer

Panzer
General
General

Posts : 980
Join date : 2008-11-17
Age : 55
Location Location : O'Fallon MO, U.S. of A

http://www.network54.com/Forum/526495/

Back to top Go down

Coconut Trees?

Post  jonlange on Sat Nov 29, 2008 7:07 am

Do you happen to have a good recipe for Coconut Trees? This has been evading me forever.

jonlange
Be nice to me I am new
Be nice to me I am new

Posts : 90
Join date : 2008-11-18
Age : 49
Location Location : Portland, Oregon U.S.A.

http://www.jonlange.blogspot.com/

Back to top Go down

Yes, great question

Post  Panzer on Mon Dec 01, 2008 6:15 pm

Jon
Great question, I would love to see a coconut tree done well.
Panzer

Panzer
General
General

Posts : 980
Join date : 2008-11-17
Age : 55
Location Location : O'Fallon MO, U.S. of A

http://www.network54.com/Forum/526495/

Back to top Go down

Coconut Trees?

Post  RickLawler on Mon Dec 01, 2008 10:06 pm

If I recal, there was a SBS floating around at some point that showed using masking tape wrapped around a "trunk" to create the pattern of the bark, then they cut paper fronds.

I'll poke around when I get the chance.

Rick

http://ricklawler.blogspot.com/

RickLawler
seasoned veteran
seasoned veteran

Posts : 451
Join date : 2008-11-17
Location Location : Portland, Oregon USA

Back to top Go down

Re: Tips & tricks 9 :Making Pine trees

Post  jonlange on Thu Dec 11, 2008 11:33 pm

Thanks, dying to do more Pacific themed stuff.

jonlange
Be nice to me I am new
Be nice to me I am new

Posts : 90
Join date : 2008-11-18
Age : 49
Location Location : Portland, Oregon U.S.A.

http://www.jonlange.blogspot.com/

Back to top Go down

Re: Tips & tricks 9 :Making Pine trees

Post  Ruben Lopez on Sun Dec 21, 2008 6:27 am

Maybe Rick is refering to this one:
http://www.armorama.com/modules.php?op=modload&name=Sections&file=index&req=viewarticle&artid=75

Hope this helps

Ruben

Ruben Lopez
seasoned veteran
seasoned veteran

Posts : 454
Join date : 2008-11-22
Age : 50
Location Location : Puerto Rico

Back to top Go down

Re: Tips & tricks 9 :Making Pine trees

Post  Guest on Fri Mar 06, 2009 6:32 pm

Palm trees we make so: http://dioramix-worx.com/BaseSites/Palme.html

Guest
Guest


Back to top Go down

Re: Tips & tricks 9 :Making Pine trees

Post  ShawnGehling on Thu Oct 15, 2009 8:16 pm

Ruben,
Love the pine... All you need is a spray can of pine scent and it would make everyone happy... lol! scratch affraid
Thanks again...
Now I have to make more Dio's.
Shawn

ShawnGehling
Platoon Commander
Platoon Commander

Posts : 1037
Join date : 2009-05-11
Age : 56
Location Location : Langley, Washington USA

Back to top Go down
